SCORPION A-3017-920KV MOTOR (A-3017-920)

P/N: A-3017-920

HK$1,027.00
HK$1,027.00 HK$1,027.00
Sale Back order

SCORPION A-3017-920KV MOTOR

The A-3017 motor series is designed specifically for 48" acrobatic airplanes, 30-32E size, and other sport/UAV airplanes require up to 962 watts of power.

The A-3017-920KV model is the premier high power choice for 4S powered 48" acrobatic airplanes or suitable UAVs.

Recommended prop selection:

  • 12x6 / 12x7 = Efficiency
  • 13x6 = For Standard Flight (not 3D)
  • 13x6.5 / 14x6 = High Alt

Recommended ESC: 6S 80A

Weight range:

  • Acrobatic: 1.3-2.18kg (46-77oz)
  • Sports/UAV (single engine/motor): 3.0-6.04kg (106-213oz)

Technical specifications:

Motor Kv 920 RPM / Volt
Weight (Motor only) 136g (4.80 oz)
Weight (including mount + accessories) 154g (5.43 oz)
Motor Body Dimensions 36.60 mm x 36.5mm (1.44" x 1.44")
External Shaft Diameter 5.98mm
Continuous Current 45A
Continuous Power 665 Watts
Peak Current 65A
Peak Power 962 Watts
Max Rated Lipo Cell** 4s
Stator Diameter 30.0 mm (1.18 in)
Stator Thickness 17 mm (0.67 in)
No. of Stator Arms 12
Magnet Poles 14
Motor Wind 6T Delta
Motor Wire 12-Strand x 0.25
No-Load Current (IO/15V) 1.86 Amps
Motor Internal Resistance (phase-phase) 25 mOhm
Motor Inductance (phase-phase) @ 1khz 8.73 uH
