Scorpion

SCORPION SII-3032-690/880/990KV (V2) MOTORS (SII-3032)

P/N: SII-3032

HK$1,178.00
HK$1,178.00 HK$1,178.00
Sale Back order

KV

If you would like to purchase these motors, please contact us directly.

SCORPION SII-3032-690/880/990KV (V2) MOTORS

Technical specifications:

Stator Diameter 30.0 mm (1.18 in)
Stator Thickness 32 mm (1.26 in)
No. of Stator Arms 12
Magnet Poles 14
Motor Wind 8/6/5 Turn Delta
Motor Wire 17-/22-/26-Strand 0.25mm
Motor Kv 690/880/990 RPM / Volt
No-Load Current (IO/10V) 2.71/3.12/4.25 Amps
Motor Resistance (Rm) 0.022/0.012/0.010 Ohms
Max Continuous Current 60/70/80 Amps
Max Continuous Power 1025/1050/1065 Watts
Weight 275 Grams (9.70 oz)
Outside Diameter 37.50 mm (1.47 in)
Shaft Diameter 4.98 mm (0.196 in)
Adapter Thread size M6*1.0
Body Length 62.5 mm (2.46 in)
Overall Shaft Length 89.5 mm (3.52 in)
Max Lipo Cell 5s
Motor Timing 5deg
Drive Frequency 8kHz
