SCORPION A-4220-540KV V2 MOTOR (A-4220-540-V2)

P/N: A-4220-540-V2

Regular price $199.99 USD
Regular price $199.99 USD Sale price $199.99 USD
Sale Back order


Technical specifications:

Motor Kv 540 RPM / Volt
Weight (Motor only) 288g ( 10.16oz)
Weight (including mount + Prop mount accessories) 336g (11.85 oz)
Motor Body Dimensions 45.8mm x 50.7mm (+12.0mm prop spacer) (1.80" x 2.00" (+ 0.47") )
External Shaft Diameter 8mm
Continuous Current 90A
Continuous Power 2000 Watts
Peak Current* 115A
Peak Power* 2553 Watts
Max Rated Lipo Cell** 6s
Stator Diameter 42.0 mm (1.65in)
Stator Thickness 25 mm (0.98in)
No. of Stator Arms 12
Magnet Poles 14
Motor Wind 5T Delta
Motor Wire 23-Strand x 0.29mm
No-Load Current (IO/15V) 1.54 Amps
Motor Internal Resistance (phase-phase) 18.2 mΩ
Motor Inductance (phase-phase) @ 1khz 10µH
