SCORPION A-4225-250/500KV V2 MOTORS (A-4225)
P/N: A-4225
Regular price
$219.99 USD
Regular price
$219.99 USD
Sale price
$219.99 USD
Unit price
per
Couldn't load pickup availability
SCORPION A-4225-250/500KV V2 MOTORS
Technical specifications:
| Motor Kv | 250/500 RPM / Volt |
| Weight (Motor only) | 350g (12.34 oz) |
| Weight (including mount + Prop mount accessories) | 398g (14.039 oz) |
| Motor Body Dimensions | 50.7mm x 50.9mm (+12.0mm prop spacer) (1.99" x 2.00") |
| External Shaft Diameter | 8mm |
| Continuous Current | 45/100A |
| Continuous Power | 2220 Watts |
| Peak Current* | 70/140A |
| Peak Power* | 3108 Watts |
| Max Rated Lipo Cell** | 12s/6s |
| Stator Diameter | 42.0 mm (1.65in) |
| Stator Thickness | 25 mm (0.98in) |
| No. of Stator Arms | 12 |
| Magnet Poles | 14 |
| Motor Wind | 10T/5T Delta |
| Motor Wire | 11-/23-Strand x 0.29mm |
| No-Load Current (IO/15V) | 1.54 Amps |
| Motor Internal Resistance (phase-phase) | 14.0 mΩ |
| Motor Inductance (phase-phase) @ 1khz | 10µH |
